Description:

Siemens Sirius 3RT1065-6A is a heavy-duty industrial motor starter contactor, suitable for starting 3-phase motors up to 100 HP @ 230 volts and 200 HP @ 460 volts. Auxiliary contacts can be front or side mounted. Plug-in overload relays are also available. All coils will work on both AC (40/50/60 Hz) and DC

3RT1065-6A Contactor Selection Chart:

3-Phase
Motor
Horsepower Built-In
Auxiliary
Contacts Cont.
Amps AC/DC Coil
Voltage Catalog #

75 hp @ 200 V
100 hp @ 230 V
200 hp @ 460 V
250 hp @ 575 V 2 - N.O.
and
2 - N.C. 330 23 - 26 3RT1065-6AB36

42 - 48 3RT1065-6AD36

110 - 127 3RT1065-6AF36

200 - 220 3RT1065-6AM36

220 - 240 3RT1065-6AP36

440 - 480 3RT1065-6AR36

Coil Power Consumption:
AC Operation:         Inrush: 490 - 590 VA.,         Sealed: 5.6 - 6.7 VA.
DC Operation:         Inrush: 540 - 650 watts,         Sealed: 6.1 - 7.4 watts.

Maximum Wire Size: Units are provided with bolts for lug attachment as standard
With bolted crimp lugs: 500 kcmil
With optional lug kit 3RT1966-4G:        2 x 500 kcmil,         1 x 600 kcmil

Click here for:          pricing         auxiliary contacts         plug-in overload relays

Dimensions:

These units have track-mounting clips for 35mm DIN-rail as standard.
Front-mounted auxiliary contacts add an extra 49mm to the depth.
Extra stacked side-mounted contacts add an extra 10mm to the side, per each block.
