Base Relays (4-pole):
With AC Coil |
Contacts
N.O. - N.C. |
Catalog # |
Price |
|
| 2 |
2 |
DILR22 photo
|
89.50 |
| 3 |
1 |
DILR31 photo
|
| 4 |
0 |
DILR40 photo
|
| 2 |
2 |
DILR22D photo
with overlapping contacts |
| |
Base Relays With Snap-On Head (8-pole):
With AC Coil |
Contacts
N.O. - N.C. |
Catalog # |
Price |
|
| 4 |
4 |
DILR40/04 photo
|
141.80 |
| 5 |
3 |
DILR40/13 photo
|
| 6 |
2 |
DILR40/22 photo
|
| 8 |
0 |
DILR40/40 photo
|
| 4 |
4 |
DILR44D photo
with overlapping contacts |
| 5 |
3 |
DILR53D
with overlapping contacts |
(numerous other configurations are available)
|
Base Relays (4-pole):
With DC Coil |
Contacts
N.O. - N.C. |
Catalog # |
Price |
|
| 2 |
2 |
DILR22-G photo
|
156.70 |
| 3 |
1 |
DILR31-G photo
|
| 4 |
0 |
DILR40-G photo
|
| 2 |
2 |
DILR22D-G
with overlapping contacts |
| |
Base Relays With Snap-On Head (8-pole):
With DC Coil. |
Contacts
N.O. - N.C. |
Catalog # |
Price |
|
| 4 |
4 |
DILR40-G/04 photo
|
209.00 |
| 5 |
3 |
DILR40-G/13 photo
|
| 6 |
2 |
DILR40-G/22 photo
|
| 8 |
0 |
DILR40-G/40 photo
|
| 4 |
4 |
DILR44D-G
with overlapping contacts |
| 5 |
3 |
DILR53D-G
with overlapping contacts |
(numerous other configurations are available)
|
| |
Auxiliary Contact Heads:
( these snap-on to any 4-pole basic relay ) |
Contacts
N.O. - N.C. |
Catalog # |
Price |
|
| 0 |
2 |
02DIL photo
|
28.50 |
| 1 |
1 |
11DIL photo
|
| 2 |
0 |
20DIL photo
|
| 0 |
4 |
04DIL photo
|
52.30 |
| 1 |
3 |
13DIL photo
|
| 2 |
2 |
22DIL photo
|
| 4 |
0 |
40DIL photo
|
| 1 |
1 |
on-delay timer:
TPE11DIL photo
|
164.00 |
| 1 |
1 |
off-delay timer:
TPD11DIL photo
|
| - |
- |
mechanical-latch relay:
VDIL photo
formerly V-DILR |
147.77 |
| - |
- |
CS-DIL00 photo
adapter plate for replacing obsolete
series DIL 00L without rail mounting. |
10.90 |
