DILM25-21

KLOCKNER MOELLER ELECTRIC
Genuine New OEM Part

$143.40
Unit price per

In stock, can ship today!

717-209-7100

Call to Order 717-209-7100
Same Day Shipping

Request More Information

DILM25-21 Klockner Moeller xStart Contactors

The Klockner Moeller DILM25-21
is a 3-phase IEC rated contactor
used for the control of electric
motors. It is rated 7.5 HP at 230V
and 15 HP at 460V. It comes with
2NO and 1NC auxiliary contact.
Conforms to IEC 60947

AC/DC Operating Coil Voltage:

Options listed below

Other DILM Contactors

TOOLS REQUIRED:

Pozidriv Screwdriver size 2

Accessories:

Auxiliary Contact Blocks

Surge Suppressors

Overload Relays:

ZB32 Motor Overload Relays

DILM25-21

AC Selection Chart:

Three phase HP ratings		Auxiliary contacts		Coil Voltage / AC Voltage	Catalog No.
230V	460V	NO	NC	Coil Voltage / AC Voltage	Catalog No.
7.5	15	2	1	24V50HZ/60HZ	DILM25-21(24V50HZ/60HZ)
				110V50HZ, 120V60HZ	DILM25-21(110V50HZ, 120V60HZ)
				208V50/60HZ	DILM25-21(208V50/60HZ)
				230V50, 240V60HZ	DILM25-21(230V50, 240V60HZ)
				415V50, 480V60HZ	DILM25-21(415V50, 480V60HZ)

DC Selection Chart:

Three phase HP ratings		Auxiliary contacts		Coil Voltage / DC Voltage	Catalog No.
230V	460V	NO	NC	Coil Voltage / DC Voltage	Catalog No.
7.5	15	2	1	24-27	DILM25-21 (RDC24)
